GE IS200TSVCH1ADC Servo Terminal Board

Overview

The GE IS200TSVCH1ADC is a high-performance servo input/output terminal board designed for integration within GE’s Mark VIe turbine control system. It facilitates precise control and monitoring of electro-hydraulic servo valves, ensuring reliable operation in gas and steam turbine applications.

Technical Specifications

• Model Number: IS200TSVCH1ADC

• Manufacturer: GE (General Electric)

• Input Voltage: 24 V DC

• Sampling Rate: 1 ms high-speed sampling

• Communication Protocol: Modbus TCP/IP

• Operating Temperature: -40°C to +85°C

• Application: Gas and steam turbine control

• Input/Output Interface: Supports analog, digital, and high-speed communication interfaces

• Vibration Resistance: Meets IEC 60068-2-6 standards

• Protection Level: IP20

• Dimensions: 28 x 15 x 5 cm

• Weight: 0.3 kg
