GE Fanuc MDP-10 Digital Overcurrent Relay

Description

• The GE Fanuc MDP-10 is a digital overcurrent relay designed for advanced protection in feeders, transmission lines, and AC machines.

• Provides precise monitoring and control, ensuring system reliability and safety.

• Supports multiple protection functions, including phase and ground time overcurrent, instantaneous overcurrent, overload protection, short circuit protection, and phase imbalance detection.

Technical Specifications

• Model Number: MDP-10

• Type: Digital Overcurrent Relay

• Current Range: 1A to 2000A

• Voltage Range: 24V DC to 240V AC/DC

• Frequency: 50/60 Hz

• Communication Protocols:

• Modbus RTU (RS-485)

• Modbus TCP/IP (Ethernet)

• Display: 2.4” LCD screen showing fault conditions, relay status, and system performance

• Event Log: Stores up to 1000 events, including fault timestamps and system status changes

• Inputs: Configurable for up to 6 digital inputs

• Outputs: Includes 3 configurable digital outputs for alarms or control functions

• Environmental Conditions:

• Operating Temperature: -20°C to +70°C (-4°F to 158°F)

• Storage Temperature: -40°C to +85°C (-40°F to 185°F)

• Relative Humidity: 5% to 95% (non-condensing)

• Protection Class: IP20 (front), IP10 (back)

• Mounting & Dimensions:

• Mounting: Panel or DIN rail mounting

• Dimensions: 145mm × 144mm × 85mm (L × W × D)

• Weight: 1.3 kg
