Allen-Bradley 185615-01 Communication Module

Product Description

The Allen-Bradley 185615-01 is an industrial-grade communication module designed to facilitate reliable data exchange within automation control systems. Typically used in conjunction with Allen-Bradley’s ControlLogix® or other PLC platforms, it ensures seamless integration of peripheral devices and subsystems using serial or specialized communication protocols.

Technical Specifications

• Module Type: Communication Interface Module

• Input Voltage: 5.1 VDC nominal (powered via backplane)

• Backplane Current Load: Approximately 1.0 A at 5.1 VDC

• Communication Ports:

• 1 or more serial channels (RS-232/RS-422/RS-485 compatible)

• Configurable baud rates and parity settings

• Data Transfer Rate: Up to 115.2 kbps

• Diagnostic Features:

• LED indicators for module status and channel activity

• Built-in diagnostics and error reporting

• Installation: DIN rail or ControlLogix chassis slot

• Isolation Voltage: 30V (continuous), basic insulation between communication ports and backplane

• Operating Temperature Range: 0 to 60°C (32 to 140°F)

• Storage Temperature Range: -40 to 85°C (-40 to 185°F)

• Humidity Tolerance: 5% to 95% non-condensing

• Dimensions: Standard ControlLogix-size module format
