HONEYWELL Power Module 2MLP-AC23
HONEYWELL Power Module 2MLP-AC23
Manufacturer: Bently Nevada
Product No.: 2MLP-AC23
Product Type: Power Module
Product Origin: USA
Payment: T/T
Weight: 600g
Shipping port: Xiamen
Warranty: 12 months
Description
The HONEYWELL 2MLP-AC23 is a compact and reliable power module designed for industrial and automation applications. It accepts a wide AC input voltage range and provides a stable DC output with built-in protection features. The module supports high-efficiency operation, incorporates overcurrent and overvoltage protection, and provides a relay output for operational status indication. Its durable construction, LED voltage indicator, and versatile cabling options make it suitable for various control systems.
Specifications
| Parameter | Details |
|---|---|
| Input | |
| Rated input voltage | AC 200V – AC 240V |
| Input voltage range | AC 170V – AC 264V |
| Input frequency | 50 / 60 Hz (47 – 63 Hz) |
| Inrush current | 20 A Peak or less |
| Efficiency | 65% or more |
| Input fuse | Built-in, UL standard (Slow Blow Type), user non-replaceable |
| Allowed instantaneous interruption | 10 ms or shorter |
| Output1 | |
| Output voltage | DC 5V (±2%) |
| Output current | 8.5A |
| Over current protection | 9.0A or more |
| Over voltage protection | 5.5V – 6.5V |
| Relay Output | |
| Application | RUN contact |
| Rated switching voltage/current | DC 24V, 0.5A |
| Minimum switching load | DC 5V, 1 mA |
| Indicators & Connections | |
| Voltage indicator | LED ON when output voltage normal |
| Cable specification | 0.75 – 2 mm² |
| Compressed terminal | RAV 1.25 – 3.5, RAV 2 – 3.5 |
| Physical | |
| Weight | 0.6 kg |
