Emerson DeltaV KJ3225X1-BK1 S-Series Analog RTD / Resistance Input Module

Emerson DeltaV KJ3225X1-BK1 S-Series Analog RTD / Resistance Input Module

  • Manufacturer: Emerson

  • Product No.: KJ3225X1-BK1

  • Product Type: Input Module

  • Product Origin: USA

  • Payment: T/T

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product Description

The Emerson DeltaV KJ3225X1-BK1 S-Series Analog RTD / Resistance Input Module is designed for precise temperature measurement using RTD and resistance inputs. It is widely used in industrial automation, particularly in hazardous environments requiring reliable monitoring.

Technical Specifications

  • Model Number: KJ3225X1-BK1

  • Type: RTD / Resistance Input Module

  • Manufacturer: Emerson

  • Input Channels: 8 channels

  • Input Type: RTD and resistance measurements

  • Power Supply: 12 VDC at 160 mA

  • Operating Temperature: -40°C to +70°C

  • Shock Resistance: 10g, ½ sinewave for 11 ms

  • Vibration Resistance:

    • 1mm peak-to-peak from 2 to 13.2 Hz

    • 0.7g from 13.2 to 150 Hz

  • Airborne Contaminants: Meets ISA-S71.04-1985 Class G3

  • Relative Humidity: 5% to 95%, non-condensing

  • Terminal Block Key Position: C3

  • Weight: 0.70 lbs
