UR‑8MH UR8MH GE Multilin CT/VT 8M Sensitive Ground 4CT/4VT Module
UR‑8MH UR8MH GE Multilin CT/VT 8M Sensitive Ground 4CT/4VT Module
Manufacturer: GE
Product No.: UR‑8MH UR8MH
Product Type: Sensitive Ground 4CT/4VT Module
Product Origin: USA
Payment: T/T
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The UR-8MH GE Multilin CT/VT 8M Sensitive Ground 4CT/4VT Module is a modular current/voltage transformer interface unit designed for GE Multilin Universal Relay (UR Series) systems. It provides precise scaling of analog signals from current transformers (CTs) and voltage transformers (VTs), along with sensitive ground fault detection, enhancing the relay’s protection and measurement capabilities. The module plugs into UR relay chassis to expand protection functions such as generator, transformer, motor, and feeder monitoring, while advanced diagnostics help maintain signal integrity and system reliability.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | UR-8MH |
| Manufacturer | GE Multilin (General Electric) |
| Product Type | CT/VT Measurement & Sensitive Ground Module |
| Series Compatibility | UR Series Universal Relays (e.g., F35, C60, G60, T60) |
| CT Inputs | 4 channels (Current Transformer inputs) |
| VT Inputs | 4 channels (Voltage Transformer inputs) |
| Ground Fault Capability | Sensitive ground fault detection enabled |
| Diagnostics | Advanced CT/VT health monitoring |
| Input Ranges | Scales high current/voltage for relay measurement (system dependent) |
| Accuracy | High-accuracy scaling (precise measurement) |
| Operating Temp. Range | –40 °C to +70 °C (typical UR series environment) |
| Weight | 0.2 kg (~0.68 kg reported in some sources) |
| Dimensions | ~6 " × 7 " × 1.5 " (approx.) |
| Construction | Rugged PCB with conformal coating for harsh environments |
| Mounting | Plug-in into UR relay chassis |
| Typical Applications | Generator, transformer, motor, and feeder protection; enhanced ground detection |
| Diagnostics & Reliability | Continuous monitoring of CT/VT health and signal quality |
